CRAWER 60W Built-In LED Work Light for John Deere R Series, Flood Beam

This built-in LED work light is designed as a flush-mount replacement for the recessed factory work lights on John Deere R Series tractors, using the original 9005 harness connector already present in the housing. It fits directly into the existing recessed opening — no cutting or bracket fabrication needed.

With a 60° flood beam and 6200 lumens of measured output, the CR-1018-60 delivers bright, even light across the work area around the tractor, and its IP68 rating means it is fully sealed against dust and can withstand temporary submersion — useful for the roof-mounted recessed position this light is built for.

(See all work lights by clicking here)

Dimensions and installation

• Type: Built-in (flush-mount), powder-coated aluminium housing
• Harness connector: 9005 (plug-and-play into the factory socket)
• Mounting: fits the existing recessed opening — no bracket or drilling required

Tip: confirm the recess on your tractor accepts a built-in (flush) light rather than a surface-mounted oval unit before ordering — the two styles are not interchangeable.

Compatibility

Designed for John Deere R Series tractors with the factory recessed (built-in) work light housing and 9005 connector.

Because it is a flush-mount design, this light is not interchangeable with the surface-mounted CR-1015 oval units — check which style your tractor uses before ordering.

Also suitable for other machines?

This unit is sized for the recessed work light opening used on John Deere R Series tractors. If your machine has a different recess size or a surface-mounted housing instead, this built-in unit won’t fit.

If you are running a different tractor and want a comparable upgrade, contact us and we will point you to the right product in our range.

Why IP68 sealing and a plug-and-play connector matter

IP68 sealing:
Built-in lights sit flush in the roof or cab, in the direct path of rain and washdown. IP68 goes beyond dust-tight and splash-proof — it means the housing and connector can handle temporary submersion without water reaching the LED chips.

Plug-and-play 9005 connector:
Using the same 9005 connector as the factory light means you can swap the old unit for the CR-1018-60 in minutes, without cutting into the existing wiring or adding an adapter.

Frequently asked questions

Why choose this CRAWER built-in LED work light at Wattz?

We specialise in LED lighting for agricultural machinery and help you choose the right solution for your setup. Read our customer feedback on Google.

The CR-1018-60 keeps the clean, factory flush-mount look of your John Deere R Series while delivering meaningfully more light than the original halogen unit, with an IP68 rating built for the harshest conditions on the roof. Order today for a drop-in upgrade with no cutting or adapters required.
