CRAWER 40W Built-In LED Work Light for Claas/Fendt

Specifications

Brand	CRAWER
Beam Angle	60° Flood Beam
Colour Temp	6000K
Electrical Protection	Radio frequency interference free I CISPR 25 class 4
Finish	Powder-coated aluminum
Harness Connector	H9
Input Voltage	10-30V
IP Rating	IP67
Lumens	4200
Output	40W

Product information

The CRAWER 40W Built-In LED Work Light is a flush-mount replacement designed to drop into the factory work light housing on Claas, Fendt, Massey Ferguson and New Holland tractors. Its 6000K cool white LEDs deliver a wide 60° flood beam across a powder-coated aluminium housing, giving broad, even coverage around the cab and working area.

Running on a 10-30V input with an H9 connector, the light matches the original wiring so there’s no cutting or splicing involved. The IP67-rated housing and CISPR 25 Class 4 certification keep it sealed against dust and moisture while staying clear of onboard electronics.

(See all Work Lights by clicking here)

Dimensions and installation

Mount: built-in, flush-fit into the factory housing
Connector: H9
Housing: powder-coated aluminium

Tip: check that your tractor still uses the original H9-fitted work light housing before ordering, as the built-in design is matched to that fitting.

Compatibility

This light is built to suit the built-in work light housings found on Claas, Fendt, Massey Ferguson and New Holland tractors, using the same H9 connector as the original halogen units.

Because the fitting and wiring match across these four brands, no adapters are needed for a factory-style swap.

Also suitable for other machines?

This light is dimensioned for the built-in H9 work light housing shared by Claas, Fendt, Massey Ferguson and New Holland, so it isn’t a guaranteed fit outside those four brands.

If you’re running a different make and want a comparable LED work light, contact us and we’ll point you to the right product in our range.

Why IP67 sealing and CISPR 25 Class 4 matter

IP67 sealing:
Built-in work lights sit exposed to rain, dust and washdown all day. An IP67 rating means the housing is fully dust-tight and can handle temporary submersion, so moisture doesn’t creep in and shorten the light’s working life.

CISPR 25 Class 4:
Modern tractors depend on sensitive onboard electronics for guidance, engine management and cab controls. CISPR 25 Class 4 certification confirms this light won’t generate radio-frequency interference that could disrupt those systems.

Frequently asked questions

Will this fit my Claas, Fendt, Massey Ferguson or New Holland tractor?

Yes, as long as your tractor uses the built-in H9-fitted work light housing shared across these four brands, it’s a direct, plug-and-play fit.

What beam pattern does this light produce?

It’s a 60° flood beam at 6000K cool white, giving wide, even coverage around the cab and working area.

Is it waterproof enough for outdoor field use?

Yes, it’s rated IP67, meaning it’s fully dust-tight and protected against temporary submersion in water.

Does it cause radio or electronics interference?

No. It’s CISPR 25 Class 4 certified, meaning it’s tested to stay clear of interfering with onboard tractor electronics.

Why choose this CRAWER 40W Built-In LED Work Light at Wattz?

We specialise in LED lighting for agricultural machinery and help you choose the right solution for your setup. Read our customer feedback on Google.

One light, four brands covered — a clean, factory-style upgrade for Claas, Fendt, Massey Ferguson and New Holland cabs with no adapters needed. Order today for a straightforward plug-and-play swap.

$130.00 AUD

$118.18 excl. GST

In stock

Part number: Part Nr.: CR-1019
